Alloy Steel WP11 Buttweld Elbow

Get a Price/Quote

MOQ : 100 Pieces

Alloy Steel WP11 Buttweld Elbow Specification

Size
Various Available

Hardness
Rigid

Corrosion Resistant
Yes

Steel Type
Carbon Steel

Grade
Various Grades Available

Steel Standard
AISI

Surface
Polished

Warranty
1 Year

Usage
Industrial

Alloy Steel WP11 Buttweld Elbow Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Alloy Steel WP11 Buttweld Elbow

Unlock astonishing savings with our first-class Alloy Steel WP11 Buttweld Elbowcrafted for industrial excellence. Available in majestic varieties of sizes and grades, this exclusive component boasts a rigid hardness and a polished, corrosion-resistant surface. Manufactured to meet the AISI standards, its premium carbon steel construction ensures superior performance and longevity. Enjoy peace of mind with a 1-year warranty on every purchase. As a trusted exporter, manufacturer, supplier, and trader in India, we deliver unmatched quality and value for global industrial needs.

Special Features & Application of Alloy Steel WP11 Buttweld Elbow

The Alloy Steel WP11 Buttweld Elbow stands out with its corrosion resistance, rigid construction, and polished finish for enduring industrial service. Specially engineered from high-quality carbon steel to match various grades, it guarantees a majestic fit for demanding applications. Simple welding or fitting processes facilitate straightforward installation, making it suitable for use in piping systems, refineries, and chemical processing plants where reliability and performance are paramount.

Delivery Time, Sample Policy, and Sales Process

Upon receipt of your purchase order, your Alloy Steel WP11 Buttweld Elbow is prepared with careful packing & dispatch strategies to guarantee protection in transit. Standard orders are fulfilled swiftly, with estimated delivery times communicated upfront. We offer a sample policysamples are available on request and may be arranged at an attractive sale price, subject to business terms. This ensures confidence before final procurement.

Specification List of Alloy Steel Butt weld Fittings

Standards	ASTM A234 / ASME SA234
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size	Seamless Butt Weld Fittings : 1/2 10 Welded Butt Weld Fittings : 1/2 48
Type	Seamless / Welded / Fabricated
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Manufacturing Standards of Alloy Steel Buttweld Fittings

ASME B16.9 ASTM A234 AS Fittings	Factory-Made Wrought Buttwelding Fittings	Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers
ASME B16.28		Short Radius Elbows, Short Radius 180-deg Returns
MSS SP43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications	Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers
MSS SP75		Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers

Alloy Steel Butt weld Fittings Dimensional Tolerances

All Fittings				90and 45 Ells and Tees	Reducers and Lap Joint Stub	Caps	180 Returns			Angularity Tol

Nominal Pipe Plane Size (NPS)	Outside(1) Diameter at Bevel	Inside(1) Diameter at End	Wall(2) Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	1/32	Not less than 87-1/2% of Normal Thickness	1/16	1/16	1/8	1/4	1/4	1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	10 to 12	3/32	3/16
4	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	1/16		1/16	1/16	1/4	1/4	1/4	1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	1/8		3/32	3/32	1/4	3/8	1/4	1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	3/32		3/32	3/32	1/4	3/8	1/4	1/16
	-3/32

FAQs of Alloy Steel WP11 Buttweld Elbow:

Q: How can I ensure the Alloy Steel WP11 Buttweld Elbow matches my specific industrial requirements?

A: You can specify the desired size and grade during your purchase. Our elbows are available in various AISI-standard grades, ensuring compatibility with diverse industrial applications.

Q: What special benefits does the corrosion-resistant and polished surface provide?

A: The corrosion-resistant, polished surface enhances the elbows durability and reduces maintenance needs, making it suitable for harsh industrial environments where longevity is essential.

Q: When should I expect delivery after placing a purchase order?

A: Once your purchase order is received, we initiate packing & dispatch. Delivery timeframes are shared upfront, depending on order size and destination.

Q: Where are these Alloy Steel WP11 Buttweld Elbows commonly used?

A: These elbows are widely used in piping systems for petrochemical, chemical, refinery, and other industrial settings where high-performance connections are paramount.

Q: What is the procedure to request a product sample before bulk purchase?

A: Simply contact our sales team with your requirements. Samples are available per our sample policyat an advantageous sale pricehelping you make an informed decision before large-scale procurement.
