Alloy Steel WP11 Stub End

Get a Price/Quote

MOQ : 100 Pieces

Alloy Steel WP11 Stub End Specification

Size
Various Available

Steel Type
Carbon Steel

Grade
Various Grades Available

Steel Standard
AISI

Surface
Polished

Warranty
1 Year

Usage
Industrial

Alloy Steel WP11 Stub End Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Alloy Steel WP11 Stub End

Experience instant savings with our Alloy Steel WP11 Stub End, an exclusive offering engineered for superlative industrial performance. In demand among top manufacturers, exporters, suppliers, and traders across India, this product is the perfect choice for diverse applications. Available in various sizes and grades, each stub end adheres to the AISI steel standard and is crafted from stellar carbon steel. Benefit from a polished surface, robust warranty of 1 year, and precise workmanship that ensures reliability and durability. Enhance your operations with this industry-leading solution.

Industrial Applications of Alloy Steel WP11 Stub End

The Alloy Steel WP11 Stub End is widely used in demanding industrial environments for superior piping connections. Primarily utilized as a connector or transitional fitting, it enables seamless joining within piping systems, supporting both high-pressure and high-temperature processes. Commonly employed in refineries, chemical plants, and energy utilities, its versatility serves varied usage types, maintaining integrity and performance under challenging conditions.

Packaging and Export Details for Alloy Steel WP11 Stub End

Each Alloy Steel WP11 Stub End is packaged securely to ensure safe transit and fast order completion across domestic and international markets. Our secure shipping methods guarantee that products reach clients in pristine condition. We provide detailed estimates to clients before dispatch and prioritize prompt delivery to main domestic hubs, as well as key export markets in Asia, Europe, and the Middle East, making us a preferred supplier worldwide.

Specification List of Alloy Steel Butt weld Fittings

Standards	ASTM A234 / ASME SA234
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size	Seamless Butt Weld Fittings : 1/2 10 Welded Butt Weld Fittings : 1/2 48
Type	Seamless / Welded / Fabricated
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Manufacturing Standards of Alloy Steel Buttweld Fittings

ASME B16.9 ASTM A234 AS Fittings	Factory-Made Wrought Buttwelding Fittings	Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers
ASME B16.28		Short Radius Elbows, Short Radius 180-deg Returns
MSS SP43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications	Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers
MSS SP75		Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers

Alloy Steel Butt weld Fittings Dimensional Tolerances

All Fittings				90and 45 Ells and Tees	Reducers and Lap Joint Stub	Caps	180 Returns			Angularity Tol

Nominal Pipe Plane Size (NPS)	Outside(1) Diameter at Bevel	Inside(1) Diameter at End	Wall(2) Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	1/32	Not less than 87-1/2% of Normal Thickness	1/16	1/16	1/8	1/4	1/4	1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	10 to 12	3/32	3/16
4	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	1/16		1/16	1/16	1/4	1/4	1/4	1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	1/8		3/32	3/32	1/4	3/8	1/4	1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	3/32		3/32	3/32	1/4	3/8	1/4	1/16
	-3/32

FAQs of Alloy Steel WP11 Stub End:

Q: How is the Alloy Steel WP11 Stub End typically used in industrial settings?

A: The Alloy Steel WP11 Stub End serves as a connector or transitional fitting in piping systems, particularly for high-pressure and high-temperature applications within industrial environments.

Q: What steel standard and type are used in the manufacturing of the WP11 Stub End?

A: These stub ends are manufactured according to AISI steel standards, crafted specifically from carbon steel, ensuring compliance and quality.

Q: When can clients expect order completion and delivery of Alloy Steel WP11 Stub End?

A: Order completion depends on the quantity and specifications, but estimated delivery timelines are promptly communicated, with secure shipping ensuring quick and reliable delivery.

Q: Where are Alloy Steel WP11 Stub Ends predominantly supplied and exported?

A: We supply both domestically across Indias industrial regions and export to major international markets such as Asia, Europe, and the Middle East.

Q: What is the process for estimating and placing an order for Alloy Steel WP11 Stub End?

A: Clients receive detailed estimates after specifying the required sizes and grades. Once confirmed, the order undergoes secure packaging and shipping for prompt fulfillment.

Q: What are the benefits of choosing a polished Alloy Steel WP11 Stub End?

A: A polished surface provides enhanced corrosion resistance, aesthetic appeal, and smoother installation, contributing to superior system performance and longevity.
