Inconel 625 Reducers

Get a Price/Quote

MOQ : 100 Pieces

Inconel 625 Reducers Specification

Hardness
Rigid

Size
Various Available

Steel Type
Carbon Steel

Grade
Various Grades Available

Steel Standard
AISI

Surface
Polished

Warranty
1 Year

Usage
Industrial

Inconel 625 Reducers Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Inconel 625 Reducers

Experience the grandiose quality of Inconel 625 Reducers at an unbeatable price for a limited time only. As a first-string exporter, manufacturer, supplier, and trader based in India, we deliver pristine reducers meticulously crafted from AISI-standard rigid carbon steel. Available in various sizes, grades, and possessing a polished, gleaming surface, these reducers are ideal for industrial settings demanding the latest in engineering excellence. All products come with a 1-year warranty, ensuring reliability and superior performance across multiple applications.

Exceptional Surface and Features for Industrial Excellence

Inconel 625 Reducers boast a polished, pristine surface, engineered for robust industrial use. With rigid hardness and broad compatibility across various sizes and grades, these reducers seamlessly support high-pressure environments. Their application extends to complex piping systems in sectors such as chemical, power generation, and manufacturing, ensuring safe operations and enhanced durability. The high performance, corrosion resistance, and reliability of these reducers guarantee optimal function in even the most demanding industrial conditions.

Reliable Supply Ability and Hassle-Free Order Processing

Our supply network ensures prompt availability of Inconel 625 Reducers, with secure shipping and guaranteed sample access to facilitate informed purchasing decisions. Order processing is streamlined and customer-oriented, offering flexible payment terms for your convenience. Products are carefully packaged and promptly delivered to your preferred location. Clients globally benefit from our trustworthy service, seamless logistics, and assurance that every order meets stringent quality standards from dispatch to delivery.

Specification List of Inconel Butt weld Fittings

Standards	ASTM A234 / ASME SA234
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size	Seamless Butt Weld Fittings : 1/2 10 Welded Butt Weld Fittings : 1/2 48
Type	Seamless / Welded / Fabricated
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Manufacturing Standards of Inconel Buttweld Fittings

ASME B16.9 ASTM A234 AS Fittings	Factory-Made Wrought Buttwelding Fittings	Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers
ASME B16.28		Short Radius Elbows, Short Radius 180-deg Returns
MSS SP43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications	Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers
MSS SP75		Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers

Inconel Butt weld Fittings Dimensional Tolerances

All Fittings				90and 45 Ells and Tees	Reducers and Lap Joint Stub	Caps	180 Returns			Angularity Tol

Nominal Pipe Plane Size (NPS)	Outside(1) Diameter at Bevel	Inside(1) Diameter at End	Wall(2) Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	1/32	Not less than 87-1/2% of Normal Thickness	1/16	1/16	1/8	1/4	1/4	1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	10 to 12	3/32	3/16
4	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	1/16		1/16	1/16	1/4	1/4	1/4	1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	1/8		3/32	3/32	1/4	3/8	1/4	1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	3/32		3/32	3/32	1/4	3/8	1/4	1/16
	-3/32

FAQs of Inconel 625 Reducers:

Q: How do Inconel 625 Reducers benefit industrial applications?

A: Inconel 625 Reducers provide exceptional corrosion resistance, rigid hardness, and a pristine, polished finish, making them ideal for demanding industrial environments such as chemical processing and power generation.

Q: What grades and sizes are available for these reducers?

A: We offer Inconel 625 Reducers in various sizes and grades to suit multiple industrial requirements, ensuring compatibility and performance for different piping systems.

Q: Where are these reducers typically utilized?

A: These reducers are commonly used in sectors like manufacturing, oil & gas, chemical, and energy, where robust and reliable piping components are essential for operation.

Q: What is the order processing time for Inconel 625 Reducers?

A: Order processing is streamlined and efficient, and products are generally shipped promptly after the order is confirmed, depending on quantity and specifications.

Q: How does secure shipping ensure product quality during delivery?

A: Secure shipping involves protective packaging and reliable logistics to guarantee that reducers arrive at your site undamaged, maintaining their pristine condition.

Q: Is a sample available before placing bulk orders?

A: Yes, we provide sample access for Inconel 625 Reducers, allowing customers to assess product quality and suitability before making a large purchase.
