Monel 400 Buttweld Cap

Get a Price/Quote

MOQ : 100 Pieces

Monel 400 Buttweld Cap Specification

Size
Various Available

Hardness
Rigid

Steel Type
Stainless Steel

Grade
Various Grades Available

Steel Standard
AISI

Surface
Polished

Warranty
1 Year

Usage
Industrial

Monel 400 Buttweld Cap Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Monel 400 Buttweld Cap

Discover the top-ranking Monel 400 Buttweld Cap, available in various sizes and offered by Indias leading exporter, manufacturer, supplier, and trader. Crafted from classic, pristine stainless steel, these rigid caps meet AISI steel standards and showcase a polished surface for an impressive finish. Customizable to your projects needs, they are available in various grades and feature a 1-year warranty. Ideal for industrial applications, the Monel 400 Buttweld Cap ensures reliable strength and performance. Get it now and experience premium quality and durability.

Versatile Industrial Usability

The Monel 400 Buttweld Cap is meticulously designed for industrial use, offering robust performance in demanding environments. Its adaptable design suits diverse application areas, from chemical plants to power generation facilities. The rigid construction ensures durability for tough usage types, making it an excellent choice for long-term reliability in high-pressure piping systems. Suitable for both new installations and maintenance, these caps offer pristine sealing that exceeds typical standards.

Efficient Delivery and Logistics Services

Our Monel 400 Buttweld Cap is managed with streamlined logistics for prompt shipping. Goods are dispatched from major FOB ports, ensuring fast and secure delivery to your location. Main domestic markets across India benefit from our reliable transport services, minimizing transit times and optimizing supply chain operations. Expect your order to arrive in pristine condition, as scheduled, thanks to our dedicated logistics team and strategic shipping facilities.

Specification List of Monel Butt weld Fittings

Standards	ASTM A234 / ASME SA234
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size	Seamless Butt Weld Fittings : 1/2 10 Welded Butt Weld Fittings : 1/2 48
Type	Seamless / Welded / Fabricated
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Manufacturing Standards of Monel Buttweld Fittings

ASME B16.9 ASTM A234 AS Fittings	Factory-Made Wrought Buttwelding Fittings	Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers
ASME B16.28		Short Radius Elbows, Short Radius 180-deg Returns
MSS SP43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications	Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers
MSS SP75		Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers

Monel Butt weld Fittings Dimensional Tolerances

All Fittings				90and 45 Ells and Tees	Reducers and Lap Joint Stub	Caps	180 Returns			Angularity Tol

Nominal Pipe Plane Size (NPS)	Outside(1) Diameter at Bevel	Inside(1) Diameter at End	Wall(2) Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	1/32	Not less than 87-1/2% of Normal Thickness	1/16	1/16	1/8	1/4	1/4	1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	10 to 12	3/32	3/16
4	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	1/16		1/16	1/16	1/4	1/4	1/4	1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	1/8		3/32	3/32	1/4	3/8	1/4	1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	3/32		3/32	3/32	1/4	3/8	1/4	1/16
	-3/32

FAQs of Monel 400 Buttweld Cap:

Q: How can I customize the Monel 400 Buttweld Cap to suit my industrial requirements?

A: You can customize the cap by selecting from various available sizes, grades, and finish options. Our team will help identify the precise specifications that match your projects needs.

Q: What surface finish is provided on the Monel 400 Buttweld Cap?

A: The cap features a polished surface, ensuring a pristine appearance and enhancing corrosion resistance in industrial environments.

Q: When will my Monel 400 Buttweld Cap order be shipped after placing an order?

A: Orders are processed promptly and shipped using efficient logistics services from major FOB ports in India. Delivery time may vary depending on the order volume and location, but fast dispatch is our priority.

Q: Where can the Monel 400 Buttweld Cap be effectively used?

A: These caps are suitable for use in chemical plants, power generation, oil and gas industries, and other high-pressure industrial applications, wherever robust sealing is required.

Q: What is the process for selecting the right grade of Monel 400 Buttweld Cap?

A: Selecting the appropriate grade depends on your specific application needs. Consult with our experts to evaluate factors such as strength, corrosion resistance, and usage environment.
