Nickel Alloy 200 Slip On Flange

Get a Price/Quote

MOQ : 100 Pieces

Nickel Alloy 200 Slip On Flange Specification

Corrosion Resistant
Yes

Grade
Multple Grades Available

Usage
Industrial

Surface Finish
Polished

Features
High Quality

Standard
ANSI

Surface
Galvanized

Technics
Cold Rolled

Size
Various Sizes Available

Nickel Alloy 200 Slip On Flange Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Nickel Alloy 200 Slip On Flange

Grab the opportunity to access our spectacular Nickel Alloy 200 Slip On Flange a lavish choice engineered for demanding industrial environments. Jump on our Imposing collection, available in multiple grades and an extensive range of sizes, perfect for ANSI-standard pipelines. Expertly manufactured using cold-rolled technics, every flange features a polished, galvanized surface for supreme corrosion resistance and high quality. We are a trusted exporter, manufacturer, supplier, and trader based in India, delivering refined finishes and robust performance for your next piping solution.

Versatile Applications & Robust Advantage

Nickel Alloy 200 Slip On Flange is widely utilized in chemical processing, oil refinement, power plants, and marine industries. Thanks to its remarkable corrosion resistance and polished finish, it stands out in aggressive settings. The cold-rolled technics ensure durability and strength, reducing maintenance needs and downtimes. This flanges adaptability, paired with high-quality material, makes it favorable for applications where reliability and safety are paramount.

Delivery Capability & Market Reach

Delivered swiftly across domestic and international markets, our Nickel Alloy 200 Slip On Flange meets freight standards to ensure safe arrival. We cater to varying supply demands, with flexibility for bulk and customized orders. Main export destinations include Europe, Middle East, Southeast Asia, and Africa, while also serving key Indian industrial hubs. Expect on-time delivery and comprehensive after-sales support, making us a preferred supplier.

Duplex Flanges Specification

Standards	ASTM A182 / ASME SA182
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2" (15 NB) to 48" (1200NB)
Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Face Types	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Super Duplex Flange Dimensions

NPS (in.)	Duplex Steel Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Duplex Flanges Weight Chart

Pipe Normal Diameter (inch)		Outer diameter Flange	Thicjness Of Flange Minimum	Diameter of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diameter of Bolt Circle	Diameter of Bolt Holes	Number of Bolts	Diameter of Bolts (inch)	KG	LB
1/2"	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2"	0.4	0.9
3/4"	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2"	0.7	1.5
1"	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2"	0.8	1.8
1-1/4"	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2"	1.2	2.6
1-1/2"	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2"	1.5	3.3
2"	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8"	2.3	5.1
2-1/2"	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8"	3.7	8.1
3"	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8"	4.1	9
3-1/2"	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8"	5.1	11.2
4"	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8"	5.9	13
5"	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4"	7	15.4
6"	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4"	8.4	18.5
8"	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4"	13	28.6
10"	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8"	18	39.5
12"	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8"	29	64
14"	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1"	39	86
16"	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1"	47	103
18"	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8"	57	126
20"	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8"	76	167
24"	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4"	97	214

Duplex Flange Pressure Rating Chart

ASME	Pressure Temperature Ratings For Duplex Steel Flanges
Temperature °F	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

FAQs of Nickel Alloy 200 Slip On Flange:

Q: How is the Nickel Alloy 200 Slip On Flange manufactured?

A: The flange is produced using advanced cold-rolled technics, resulting in high strength, uniform surface, and enhanced durability suitable for heavy-duty industrial applications.

Q: What are the primary benefits of using this Nickel Alloy 200 Slip On Flange?

A: Key advantages include outstanding corrosion resistance, polished galvanized finish, compliance with ANSI standards, and a wide range of available sizes to suit various industrial pipelines.

Q: Where can this Slip On Flange be used?

A: It is ideal for sectors such as chemical processing, oil and gas, power generation, marine engineering, and environments requiring superior corrosion resistance.

Q: What is the process to order and receive these flanges?

A: Simply contact us with your requirements. Upon confirmation, your order will be processed, safely packed, and shipped via trusted freight partners to ensure timely arrival.

Q: How does the surface finish contribute to the flanges performance?

A: The polished and galvanized surface enhances the flanges resistance to corrosion, wear, and tear, ensuring a longer operational lifespan in harsh industrial environments.
