Send InquirySS Round Bar
MOQ : 1 Ton
SS Round Bar Specification
- Material
- SS
- Features
- High Quality
- Application
- Industrial
- Shape
- Round
- Finish
- Polished
- Surface Finish
- Mill Finish
- Material Grade
- SS
SS Round Bar Trade Information
- Minimum Order Quantity
- 1 Ton
- Payment Terms
- Cash in Advance (CID)
- Main Domestic Market
- All India
About SS Round Bar
| Standards | ASTM A276, A580 / ASME SA276, SA580 |
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI all International Standards |
| Diameter | Outside Diameter in the range of 4mm to 500mm |
| Width | 1m to 48 |
| Hex Bars | 18mm 57mm (11/16 to 2-3/4) |
| Square Bars | 18mm 47mm (11/16 to 1-3/4) |
| Flat Bars | 1/2 to 10 in the thickness range of 2mm to 150mm |
| Wire Length | Max 12000 mm |
| Wire Diameter | 5.5 400 mm |
| Length | 1 to 6 Meters, Custom Cut Lengths |
| Types | Round, Square, Hex (A/F), Flat, Square, Rectangle, Billet, Ingot, Forging, Wire Bobbin, Wire Spool, Wire Rope, Spring Wires, Welding Wire, Coiled Wire Etc. |
| Finish | Soft annealed - hard, hard, hard, full hard (Matte or Bright finish) |
Equivalent Grades Of Stainless Steel 304 Rod, Bar, Wire
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 304 | 1.4301 | S30400 | SUS 304 | 304S31 | 081810 | Z7CN18-09 | X5CrNi18-10 |
Chemical Composition of Stainless Steel 304 Rod, Bar, Wire
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304 | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 18 20 | 8 11 |
Mechanical Properties of SS 304 Rod, Bar, Wire
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 304 | 8.0 g/cm3 | 1400 C (2550 F) | Psi 75000 , MPa 515 | Psi 30000 , MPa 205 | 35 % |
Stainless Steel 304 Rod, Bars Sizes
| Size and Dimensions of Rod | |||||||
|---|---|---|---|---|---|---|---|
| Metric | US Rods | ASTM/ Canadian | Japanese | ||||
| Rods Size | Diam. (mm) | Rods Size | Diam. (Inch) | Rods Size | Diam. (mm2) | Rods Size | Diam. (mm) |
| 5 | 5 | #2 | 0.250 | 10M | 100 | 6 | 6 |
| 5.5 | 5.5 | #3 | 0.375 | 15M | 200 | 10 | 10 |
| 6 | 6 | #4 | 0.500 | 20M | 300 | 13 | 13 |
| 7 | 7 | #5 | 0.600 | 25M | 500 | 16 | 16 |
| 8 | 8 | #6 | 0.750 | 30M | 700 | 19 | 19 |
| 9 | 9 | #7 | 0.875 | 35M | 1000 | 22 | 22 |
| 10 | 10 | #8 | 1.000 | 45M | 1500 | 25 | 25 |
| 11 | 11 | #9 | 1.125 | 55M | 2500 | 29 | 29 |
| 12 | 12 | #10 | 1.250 | 32 | 32 | ||
| 14 | 14 | #11 | 1.375 | 35 | 35 | ||
| 16 | 16 | #12 | 1.500 | 38 | 38 | ||
| 18 | 18 | #13 | 1.600 | 41 | 41 | ||
| 20 | 20 | #14 | 1.750 | 44 | 44 | ||
| 22 | 22 | #15 | 1.875 | 48 | 48 | ||
| 25 | 25 | #16 | 2.000 | 51 | 51 | ||
| 28 | 28 | #18 | 2.250 | 57 | 57 | ||
| 32 | 32 | ||||||
| 36 | 36 | ||||||
| 40 | 40 | ||||||
| 44 | 44 | ||||||
| 50 | 50 | ||||||
Stainless Steel 304 Rods, Bars Weight Chart
| Round Rod | ||||||||
| Size | Kgs / Foot | Kgs / Mtr | Size | Kgs / Foot | Kgs / Mtr | Size | Kgs / Foot | Kgs / Mtr |
| 3mm | 0.017 | 0.055 | 20mm | 0.753 | 2.470 | 3 | 10.900 | 35.762 |
| 1/8 | 0.019 | 0.062 | 22mm | 0.908 | 2.979 | 3-1/4 | 12.800 | 41.996 |
| 5/32 | 0.029 | 0.095 | 7/8 | 0.926 | 3.038 | 3-1/2 | 14.850 | 48.772 |
| 4mm | 0.030 | 0.098 | 24mm | 1.080 | 3.543 | 3-3/4 | 17.001 | 55.780 |
| 3/16 | 0.043 | 0.141 | 25mm | 1.180 | 3.871 | 4 | 19.306 | 63.340 |
| 5mm | 0.047 | 0.154 | 1 | 1.210 | 3.970 | 4-1/4 | 21.908 | 72.249 |
| 7/32 | 0.058 | 0.190 | 26mm | 1.271 | 4.170 | 4-1/2 | 24.4487 | 80.340 |
| 6mm | 0.068 | 0.223 | 27mm | 1.368 | 4.490 | 4-3/4 | 27.366 | 90.249 |
| 1/4 | 0.076 | 0.249 | 1-1/8 | 1.534 | 5.033 | 5 | 30.461 | 99.940 |
| 7mm | 0.091 | 0.298 | 30mm | 1.691 | 5.548 | 5-1/2 | 36.690 | 121.000 |
| 5/16 | 0.118 | 0.387 | 1-1/4 | 1.924 | 6.349 | 6 | 43.860 | 143.900 |
| 8mm | 0.120 | 0.398 | 32mm | 1.894 | 6.314 | 6-1/2 | 51.093 | 167.630 |
| 9mm | 0.152 | 0.498 | 1-3/8 | 2.303 | 7.550 | 7 | 59.432 | 196.000 |
| 3/8 | 0.170 | 0.557 | 35mm | 2.390 | 7.553 | 7-1/2 | 68.226 | 225.000 |
| 10mm | 0.189 | 0.620 | 36mm | 2.438 | 7.999 | 8 | 77.586 | 254.55 |
| 11mm | 0.228 | 0.748 | 38mm | 2.792 | 8.903 | 10 | 121.048 | 397.140 |
| 7/16 | 0.232 | 0.761 | 1-1/2 | 2.715 | 8.951 | |||
| 12mm | 0.271 | 0.889 | 40mm | 3.009 | 9.872 | |||
| 1/2 | 0.303 | 0.994 | 1-5/8 | 3.200 | 10.449 | |||
| 13mm | 0.318 | 1.043 | 1-3/4 | 3.712 | 12.179 | |||
| 14mm | 0.368 | 1.207 | 45mm | 3.807 | 12.555 | |||
| 9/16 | 0.383 | 1.256 | 1-7/8 | 4.260 | 13.977 | |||
| 15mm | 0.424 | 1.391 | 48mm | 4.330 | 14.205 | |||
| 5/8 | 0.473 | 1.551 | 50mm | 4.698 | 15.414 | |||
| 16mm | 0.481 | 1.578 | 2 | 4.848 | 15.906 | |||
| 17mm | 0.543 | 1.791 | 2-1/8 | 5.475 | 17.963 | |||
| 11/16 | 0.573 | 1.880 | 2-1/4 | 6.135 | 20.128 | |||
| 18mm | 0.610 | 2.001 | 60mm | 6.768 | 22.205 | |||
| 3/4 | 0.682 | 2.237 | 2-3/8 | 6.838 | 22.435 | |||
| 2-1/2 | 7.576 | 24.856 | ||||||
| 2-5/8 | 8.354 | 27.409 | ||||||
| 2-3/4 | 9.169 | 30.083 | ||||||
