Send InquirySuper Duplex Steel 2507 Long Weld Neck Flange
About Super Duplex Steel 2507 Long Weld Neck Flange
Experience a magnificent Hot Deal on the Super Duplex Steel 2507 Long Weld Neck Flange the last chance to Get It Now from Indias invincible exporter, manufacturer, supplier, and trader! Crafted to splendiferous perfection, these industrial-grade flanges are available in various sizes and multiple grades, ensuring seamless integration into any system. Boasting galvanization, a polished surface finish, and outstanding corrosion resistance, this high-quality stainless steel flange meets stringent ANSI standards, delivering robust and dependable performance. Dont miss this exclusive offerupgrade your industrial applications with a product built for excellence.
Material Advantage and Versatile Applications
The Super Duplex Steel 2507 Long Weld Neck Flange features a polished, galvanized surface that provides exceptional corrosion resistance. Its high-quality stainless steel composition ensures durability and suitability for various industrial purposes, making it ideal for both general and specific uses across multiple sectors. The flanges design allows it to withstand demanding operational environments and offers optimal compatibility, ensuring trouble-free application and long-lasting performance wherever reliability is crucial.
Payment Terms, Certifications, and Shipping Details
Secure your order with flexible payment terms upon Arrival at port, ensuring a streamlined transaction from Indias premier exporter. Each Super Duplex Steel 2507 Long Weld Neck Flange is accompanied by internationally recognized certifications, testifying to its unsurpassed quality. We offer competitive Freight rates and reliable FOB Port options, providing timely delivery and outstanding logistics support for our global clientele. Rest assured in the quality and efficiency this product brings, from the moment of order to shipment.
Material Advantage and Versatile Applications
The Super Duplex Steel 2507 Long Weld Neck Flange features a polished, galvanized surface that provides exceptional corrosion resistance. Its high-quality stainless steel composition ensures durability and suitability for various industrial purposes, making it ideal for both general and specific uses across multiple sectors. The flanges design allows it to withstand demanding operational environments and offers optimal compatibility, ensuring trouble-free application and long-lasting performance wherever reliability is crucial.
Payment Terms, Certifications, and Shipping Details
Secure your order with flexible payment terms upon Arrival at port, ensuring a streamlined transaction from Indias premier exporter. Each Super Duplex Steel 2507 Long Weld Neck Flange is accompanied by internationally recognized certifications, testifying to its unsurpassed quality. We offer competitive Freight rates and reliable FOB Port options, providing timely delivery and outstanding logistics support for our global clientele. Rest assured in the quality and efficiency this product brings, from the moment of order to shipment.
Duplex Flanges Specification
| Standards | ASTM A182 / ASME SA182 |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Size | 1/2" (15 NB) to 48" (1200NB) |
| Class | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Flange Face Types | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
Super Duplex Flange Dimensions
| NPS (in.) | Duplex Steel Flange Dimensions | ||||
|---|---|---|---|---|---|
| Dia. of Flange (in.) | No. of Bolts | Dia. of Bolts (in.) | Dia. of Bolt Holes (in.) | Bolt Circle (in.) | |
| 1/4 | 3-3/8 | 4 | 1/2 | 0.62 | 2-1/4 |
| 1/2 | 3-1/2 | 4 | 1/2 | 0.62 | 2-3/8 |
| 3/4 | 3-7/8 | 4 | 1/2 | 0.62 | 2-3/4 |
| 1 | 4-1/4 | 4 | 1/2 | 0.62 | 3-1/8 |
| 1-1/4 | 4-5/8 | 4 | 1/2 | 0.62 | 3-1/2 |
| 1-1/2 | 5 | 4 | 1/2 | 0.62 | 3-7/8 |
| 2 | 6 | 4 | 5/8 | 0.75 | 4-3/4 |
| 2-1/2 | 7 | 4 | 5/8 | 0.75 | 5-1/2 |
| 3 | 7-1/2 | 4 | 5/8 | 0.75 | 6 |
| 3-1/2 | 8-1/2 | 8 | 5/8 | 0.75 | 7 |
| 4 | 9 | 8 | 5/8 | 0.75 | 7-1/2 |
| 5 | 10 | 8 | 3/4 | 0.88 | 8-1/2 |
| 6 | 11 | 8 | 3/4 | 0.88 | 9-1/2 |
| 8 | 13-1/2 | 8 | 3/4 | 0.88 | 11-3/4 |
| 10 | 16 | 12 | 7/8 | 1 | 14-1/4 |
| 12 | 19 | 12 | 7/8 | 1 | 17 |
| 14 | 21 | 12 | 1 | 1.12 | 18-3/4 |
| 16 | 23-1/2 | 16 | 1 | 1.12 | 21-1/4 |
| 18 | 25 | 16 | 1-1/8 | 1.25 | 22-3/4 |
| 20 | 27-1/2 | 20 | 1-1/8 | 1.25 | 25 |
| 24 | 32 | 20 | 1-1/4 | 1.38 | 29-1/2 |
Duplex Flanges Weight Chart
| Pipe Normal Diameter (inch) | Outer diameter Flange | Thicjness Of Flange Minimum | Diameter of Hub | Diameter of Raised Face | Length Hub.Y | Thread Length | Diameter of Bolt Circle | Diameter of Bolt Holes | Number of Bolts | Diameter of Bolts (inch) | KG | LB | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1/2" | 15 | 89.00 | 11.20 | 30.20 | 35.10 | 15.70 | 15.70 | 60.50 | 15.80 | 4 | 1/2" | 0.4 | 0.9 |
| 3/4" | 20 | 98.50 | 12.70 | 38.10 | 42.90 | 15.70 | 15.70 | 69.90 | 15.80 | 4 | 1/2" | 0.7 | 1.5 |
| 1" | 25 | 108.00 | 14.20 | 49.30 | 50.80 | 17.50 | 17.50 | 79.30 | 15.80 | 4 | 1/2" | 0.8 | 1.8 |
| 1-1/4" | 32 | 117.50 | 15.70 | 58.70 | 63.50 | 20.60 | 20.60 | 88.90 | 15.80 | 4 | 1/2" | 1.2 | 2.6 |
| 1-1/2" | 40 | 127.00 | 17.50 | 65.00 | 73.20 | 22.40 | 22.40 | 98.60 | 15.80 | 4 | 1/2" | 1.5 | 3.3 |
| 2" | 50 | 152.50 | 19.10 | 77.70 | 91.90 | 25.40 | 25.40 | 120.70 | 19.10 | 4 | 5/8" | 2.3 | 5.1 |
| 2-1/2" | 65 | 178.00 | 22.40 | 90.40 | 104.60 | 28.40 | 28.40 | 139.70 | 19.10 | 4 | 5/8" | 3.7 | 8.1 |
| 3" | 80 | 190.50 | 23.90 | 108.00 | 127.00 | 30.20 | 30.20 | 152.40 | 19.10 | 4 | 5/8" | 4.1 | 9 |
| 3-1/2" | 90 | 216.00 | 23.90 | 122.20 | 139.70 | 31.80 | 31.80 | 177.80 | 19.10 | 8 | 5/8" | 5.1 | 11.2 |
| 4" | 100 | 228.50 | 23.90 | 134.90 | 157.20 | 33.30 | 33.30 | 190.50 | 19.10 | 8 | 5/8" | 5.9 | 13 |
| 5" | 125 | 254.00 | 23.90 | 163.60 | 185.70 | 36.60 | 36.60 | 215.90 | 22.40 | 8 | 3/4" | 7 | 15.4 |
| 6" | 150 | 279.50 | 25.40 | 192.00 | 215.90 | 39.60 | 39.60 | 241.30 | 22.40 | 8 | 3/4" | 8.4 | 18.5 |
| 8" | 200 | 343.00 | 28.40 | 246.10 | 269.70 | 44.50 | 44.50 | 298.50 | 22.40 | 8 | 3/4" | 13 | 28.6 |
| 10" | 250 | 406.50 | 30.20 | 304.80 | 323.90 | 49.30 | 49.30 | 362.00 | 25.40 | 12 | 7/8" | 18 | 39.5 |
| 12" | 300 | 482.50 | 31.80 | 365.30 | 381.00 | 55.60 | 55.60 | 431.80 | 25.40 | 12 | 7/8" | 29 | 64 |
| 14" | 350 | 533.50 | 35.10 | 400.10 | 412.80 | 57.20 | 57.20 | 476.30 | 28.50 | 12 | 1" | 39 | 86 |
| 16" | 400 | 597.00 | 36.60 | 457.20 | 469.90 | 63.50 | 63.50 | 539.80 | 28.50 | 16 | 1" | 47 | 103 |
| 18" | 450 | 635.00 | 39.60 | 505.00 | 533.40 | 68.30 | 68.30 | 577.90 | 31.80 | 16 | 1 1/8" | 57 | 126 |
| 20" | 500 | 698.50 | 42.90 | 558.80 | 584.20 | 73.20 | 73.20 | 635.00 | 31.80 | 20 | 1 1/8" | 76 | 167 |
| 24" | 600 | 813.00 | 47.80 | 663.40 | 692.20 | 82.60 | 82.60 | 749.30 | 35.10 | 20 | 1 1/4" | 97 | 214 |
Duplex Flange Pressure Rating Chart
| ASME | Pressure Temperature Ratings For Duplex Steel Flanges | ||||||
| Temperature °F | Class 150 | Class 300 | Class 400 | Class 600 | Class 900 | Class 1500 | Class 2500 |
| -20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
| 200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
| 300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
| 400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
| 500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
| 600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
| 650 | 125 | 430 | 575 | 860 | 1290 | 2150 | 3580 |
| 700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
| 750 | 95 | 415 | 555 | 830 | 1245 | 2075 | 3460 |
| 800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
| 850 | 65 | 395 | 530 | 790 | 1190 | 1980 | 3300 |
| 900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
| 950 | 35 | 380 | 510 | 765 | 1145 | 1910 | 3180 |
| 1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
| 1050 | 20 | 310 | 410 | 615 | 925 | 1545 | 2570 |
| 1100 | 20 | 255 | 345 | 515 | 770 | 1285 | 2145 |
| 1150 | 20 | 200 | 265 | 400 | 595 | 995 | 1655 |
| 1200 | 20 | 155 | 205 | 310 | 465 | 770 | 1285 |
| 1250 | 20 | 115 | 150 | 225 | 340 | 565 | 945 |
| 1300 | 20 | 85 | 115 | 170 | 255 | 430 | 715 |
| 1350 | 20 | 60 | 80 | 125 | 185 | 310 | 515 |
| 1400 | 20 | 50 | 65 | 95 | 145 | 240 | 400 |
| 1450 | 15 | 35 | 45 | 70 | 105 | 170 | 285 |
| 1500 | 10 | 25 | 35 | 55 | 80 | 135 | 230 |
Q: How does the Super Duplex Steel 2507 Long Weld Neck Flange benefit industrial operations?
A: Its magnificent corrosion resistance and robust construction make it ideal for high-pressure, harsh industrial environments, reducing maintenance and increasing system longevity.Q: What certifications come with the Super Duplex Steel 2507 flange?
A: Each flange is supplied with internationally recognized quality and material certifications, ensuring compliance with ANSI and other industry standards.Q: When should I choose the Super Duplex Steel 2507 Long Weld Neck Flange over standard types?
A: Opt for this flange when requiring exceptional corrosion resistance, higher strength, and reliability under demanding conditions, especially where longevity and minimal downtime are critical.Q: Where can the Super Duplex Steel 2507 Long Weld Neck Flange be utilized?
A: It is designed for use in various industrial sectors, including oil & gas, chemical processing, and marine applications, wherever corrosion resistance and strength are paramount.Q: What is the process for ordering and receiving the product internationally?
A: You can place your order through our channels as a supplier, trader, or exporter. The flange is shipped under FOB terms with efficient freight solutions and prompt port arrival to your location.
