Titanium Grade 2 Buttweld Elbow

Get a Price/Quote

MOQ : 100 Pieces

Titanium Grade 2 Buttweld Elbow Specification

Size
Various Available

Hardness
Rigid

Corrosion Resistant
Yes

Steel Type
Carbon Steel

Grade
Various Grades Available

Steel Standard
AISI

Surface
Polished

Warranty
1 Year

Usage
Industrial

Titanium Grade 2 Buttweld Elbow Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Titanium Grade 2 Buttweld Elbow

Experience the commanding quality and scarce availability of the Titanium Grade 2 Buttweld Elbowa wondrous addition to any industrial setup. Crafted to rigid AISI steel standards, these elbows boast impressive corrosion resistance and a polished surface for enduring value. With various sizes and grades on offer, each piece is special, promising superior durability for heavy-duty use. Backed by a 1-year warranty and representing valuable investment, this product is available from Indias leading exporter, manufacturer, supplier, and trader. Get It Now to lift your industrial capabilities with unrivalled performance.

Features and Applications of Titanium Grade 2 Buttweld Elbow

The Titanium Grade 2 Buttweld Elbow is machined for precision, ensuring a perfect fit and reliable joint strength. Application is straightforward via welding, suitable for integration into pipeline systems and machinery. Its high rigidity and corrosion resistance make it ideal for use in chemical plants, oil refineries, and power stations, providing long-term reliability where demanding environments require robust solutions.

Packaging, Payment, and Supply for Titanium Grade 2 Buttweld Elbow

Our elbows are shipped securely using advanced logistics to guarantee safe arrival. Packaging conforms to industry standards for international shipment, ensuring product integrity. Flexible payment terms are available, including competitive rates for bulk orders. With a strong supply ability, we support continual demand and timely delivery to clients worldwide, accommodating both small and large purchase requirements with efficient transport arrangements.

Specification List of Titanium Butt weld Fittings

Standards	ASTM A234 / ASME SA234
Dimensions	ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
Size	Seamless Butt Weld Fittings : 1/2 10 Welded Butt Weld Fittings : 1/2 48
Type	Seamless / Welded / Fabricated
Thickness	SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Manufacturing Standards of Titanium Buttweld Fittings

ASME B16.9 ASTM A234 AS Fittings	Factory-Made Wrought Buttwelding Fittings	Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers
ASME B16.28		Short Radius Elbows, Short Radius 180-deg Returns
MSS SP43	Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications	Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers
MSS SP75		Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers

Titanium Butt weld Fittings Dimensional Tolerances

All Fittings				90and 45 Ells and Tees	Reducers and Lap Joint Stub	Caps	180 Returns			Angularity Tol

Nominal Pipe Plane Size (NPS)	Outside(1) Diameter at Bevel	Inside(1) Diameter at End	Wall(2) Thickness	Centre-to- End Dimension A,B,C,M	Overall Length L	Overall Length E	Centre-to- Centre Dimension O	Back-to- Face Dimension K	Alignment at Ends U	Nominal Pipe SIze	Off Angle Q	Off Angle P
1/2 TO 2-1/2	+1/16	1/32	Not less than 87-1/2% of Normal Thickness	1/16	1/16	1/8	1/4	1/4	1/32	12 to 4	1/32	1/16
	-1/32									5 to 8	1/16	1/8
3 TO 3-1/2	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	10 to 12	3/32	3/16
4	1/16	1/16		1/16	1/16	1/8	1/4	1/4	1/32	14 to 16	3/32	1/4
5 TO 8	+1/32	1/16		1/16	1/16	1/4	1/4	1/4	1/32	18 to 24	1/8	3/8
	-1/16
10 TO 18	+1/16	1/8		3/32	3/32	1/4	3/8	1/4	1/16	All dimensions are in inches
	-1/8
20 TO 24	+1/4	3/32		3/32	3/32	1/4	3/8	1/4	1/16
	-3/32

FAQs of Titanium Grade 2 Buttweld Elbow:

Q: How is the Titanium Grade 2 Buttweld Elbow installed in industrial applications?

A: The elbow is typically welded onto pipeline systems, using standard buttweld techniques that ensure a secure and leak-proof connection.

Q: What are the main benefits of choosing a Titanium Grade 2 Buttweld Elbow?

A: This product offers excellent corrosion resistance, high rigidity, and durability, making it valuable for demanding environments where reliability is crucial.

Q: Where can these buttweld elbows be used?

A: They are widely used in places such as chemical plants, oil refineries, power generation stations, and other industrial facilities requiring robust pipe fittings.

Q: What process is involved in packaging and shipment?

A: The elbows are packaged with care to ensure safe transport, using protective material and proven logistics to maintain product quality during shipment.

Q: When can customers expect delivery upon ordering?

A: Delivery times depend on order volume and destination, but our efficient supply chain ensures timely shipment and quick rate negotiation for each order.

Q: How does the one-year warranty support buyers?

A: The included warranty covers manufacturing defects, providing buyers with assurance and support for potential replacements or repairs within the warranty period.
