Hastelloy C276 Orifice Flange

Get a Price/Quote

MOQ : 100 Pieces

Hastelloy C276 Orifice Flange Specification

Usage
Industrial

Corrosion Resistant
Yes

Features
High Quality

Surface Finish
Polished

Grade
Multple Grades Available

Standard
ANSI

Surface
Galvanized

Technics
Cold Rolled

Size
Various Sizes Available

Hastelloy C276 Orifice Flange Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Hastelloy C276 Orifice Flange

Highlighted as a clearance opportunity for industrial procurement, our top-tier Hastelloy C276 Orifice Flange represents a monumental advancement in flow measurement solutions. This illustrious product is manufactured and exported from India, constructed from multiple grades of Hastelloy C276, ensuring optimum, long-lasting performance even in corrosive environments. With a sleek galvanized, cold-rolled, and polished surface, it adheres to the ANSI standard and is available in various sizes. Choose this high-quality, corrosion-resistant orifice flange from a top-rated supplier, manufacturer, and exporter for assured durability and efficiency in demanding applications.

Outstanding Surface Application and Competitive Advantages

Engineered for superior resilience, the Hastelloy C276 Orifice Flange is galvanized and polished, making it ideal for challenging environments where corrosion resistance is paramount. Its monumental design ensures longevity, while its top-tier cold-rolled technics provide consistent quality. Available in multiple sizes and grades, this flange supports diverse industrial processes. Competitive advantages include compliance with ANSI standards, highlighted operational reliability, and the flexibility offered by an illustrious range of sizes for seamless installation.

Sample Availability, Secure Packaging, and Swift Delivery

Experience our illustrious customer-centric service with sample availability upon request. All orders are thoroughly packaged to prevent transit damage, ensuring the surface finish remains pristine. Upon acceptance of a Purchase Order, products are quickly dispatched, streamlining supply and delivery to meet strict industrial timelines. As a renowned exporter and supplier, we prioritize prompt shipping, securing your project schedules with reliable support from order to delivery.

Duplex Flanges Specification

Standards	ASTM A182 / ASME SA182
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2" (15 NB) to 48" (1200NB)
Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Face Types	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Super Duplex Flange Dimensions

NPS (in.)	Duplex Steel Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Duplex Flanges Weight Chart

Pipe Normal Diameter (inch)		Outer diameter Flange	Thicjness Of Flange Minimum	Diameter of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diameter of Bolt Circle	Diameter of Bolt Holes	Number of Bolts	Diameter of Bolts (inch)	KG	LB
1/2"	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2"	0.4	0.9
3/4"	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2"	0.7	1.5
1"	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2"	0.8	1.8
1-1/4"	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2"	1.2	2.6
1-1/2"	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2"	1.5	3.3
2"	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8"	2.3	5.1
2-1/2"	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8"	3.7	8.1
3"	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8"	4.1	9
3-1/2"	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8"	5.1	11.2
4"	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8"	5.9	13
5"	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4"	7	15.4
6"	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4"	8.4	18.5
8"	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4"	13	28.6
10"	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8"	18	39.5
12"	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8"	29	64
14"	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1"	39	86
16"	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1"	47	103
18"	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8"	57	126
20"	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8"	76	167
24"	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4"	97	214

Duplex Flange Pressure Rating Chart

ASME	Pressure Temperature Ratings For Duplex Steel Flanges
Temperature °F	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

FAQs of Hastelloy C276 Orifice Flange:

Q: How is the surface of the Hastelloy C276 Orifice Flange specially treated for corrosion resistance?

A: The Hastelloy C276 Orifice Flange is galvanized, polished, and manufactured using a cold-rolled technique, providing a robust surface finish that excels in resisting corrosion, even in highly aggressive industrial environments.

Q: What makes this orifice flange a competitive option for industrial applications?

A: This orifice flange stands out due to its high-quality construction, adherence to ANSI standards, and availability in multiple grades and sizes. Its top-rated corrosion resistance and operational durability deliver lasting value in demanding settings.

Q: When can samples be supplied for evaluation before placing an order?

A: Samples of the Hastelloy C276 Orifice Flange are available upon request. Upon receiving your Purchase Order, we promptly organize sample dispatch to ensure timely product evaluation.

Q: Where is your main manufacturing and supply base located?

A: Our manufacturing and supply operations are based in India, catering to both domestic and international clients with reliable, high-standard industrial products.

Q: What is the typical delivery process after a purchase order is confirmed?

A: Once a purchase order is accepted, we package the flanges securely and dispatch them swiftly. Our dedicated supply chain ensures that delivery is punctual, regardless of your projects scale or location.

Q: How can industrial users benefit from utilizing this orifice flange in their systems?

A: Industrial users benefit from its consistent accuracy in flow measurement, monumental corrosion resistance, and illustrious durability, minimizing maintenance and replacement costs over time.
