Hastelloy C276 Socket Weld Flange

Get a Price/Quote

MOQ : 100 Pieces

Hastelloy C276 Socket Weld Flange Specification

Grade
Multple Grades Available

Features
High Quality

Usage
Industrial

Surface Finish
Polished

Corrosion Resistant
Yes

Standard
ANSI

Surface
Galvanized

Technics
Cold Rolled

Size
Various Sizes Available

Hastelloy C276 Socket Weld Flange Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Hastelloy C276 Socket Weld Flange

Redeem the excellence of engineering with the trending Hastelloy C276 Socket Weld Flange, distinguished by its imposing corrosion resistance and resplendent polished finish. Available in multiple grades and a spectrum of sizes, this top-tier industrial component is crafted to ANSI standards by expert exporters, manufacturers, suppliers, and traders in India. The galvanized, cold-rolled technics ensure remarkable durability for high-demand sectors. Reserve your solution for robust, reliable, and high-quality connections where performance and longevity are paramount. Secure advanced, corrosion-resistant technology for your project today.

Versatile Applications and Superior Features

Hastelloy C276 Socket Weld Flanges are engineered to excel on demanding application surfaces, especially where chemical resistance is critical. Their polished and galvanized finishes enhance endurance against harsh industrial environments. Featuring exceptional quality, these flanges are ideally suited for industries like petrochemicals, power generation, and marine engineering. The cold-rolled process and resplendent surface finish guarantee optimal fit and longevity, affirming their place as a key component in high-performance piping systems.

Efficient Sample Policy & Reliable Supply

We provide Hastelloy C276 Socket Weld Flange samples at the lowest price for client evaluation. Rely on swift supply and quick dispatch, ensuring timely project completion. Each item is meticulously packaged to prevent damage during transit, reinforcing our commitment to quality. Our flexible sample policy allows potential buyers to assess top-tier materials before committing to bulk orders. Experience prompt delivery and premium packaginga hallmark of our trusted supply chain.

Duplex Flanges Specification

Standards	ASTM A182 / ASME SA182
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2" (15 NB) to 48" (1200NB)
Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Face Types	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Super Duplex Flange Dimensions

NPS (in.)	Duplex Steel Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Duplex Flanges Weight Chart

Pipe Normal Diameter (inch)		Outer diameter Flange	Thicjness Of Flange Minimum	Diameter of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diameter of Bolt Circle	Diameter of Bolt Holes	Number of Bolts	Diameter of Bolts (inch)	KG	LB
1/2"	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2"	0.4	0.9
3/4"	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2"	0.7	1.5
1"	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2"	0.8	1.8
1-1/4"	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2"	1.2	2.6
1-1/2"	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2"	1.5	3.3
2"	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8"	2.3	5.1
2-1/2"	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8"	3.7	8.1
3"	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8"	4.1	9
3-1/2"	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8"	5.1	11.2
4"	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8"	5.9	13
5"	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4"	7	15.4
6"	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4"	8.4	18.5
8"	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4"	13	28.6
10"	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8"	18	39.5
12"	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8"	29	64
14"	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1"	39	86
16"	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1"	47	103
18"	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8"	57	126
20"	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8"	76	167
24"	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4"	97	214

Duplex Flange Pressure Rating Chart

ASME	Pressure Temperature Ratings For Duplex Steel Flanges
Temperature °F	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

FAQs of Hastelloy C276 Socket Weld Flange:

Q: How do I reserve a sample of the Hastelloy C276 Socket Weld Flange?

A: You can reserve a sample by contacting our sales team. We offer samples at the lowest price, with quick dispatch to ensure you get them promptly for evaluation.

Q: What areas of industrial application benefit most from this flange?

A: Industries such as petrochemical, marine, and power generation benefit significantly from the corrosion resistance and durability of the Hastelloy C276 Socket Weld Flange.

Q: Where can these flanges be installed efficiently?

A: These flanges can be seamlessly installed in any industrial setup requiring secure, corrosion-resistant joints, especially in harsh chemical or marine environments.

Q: What makes your supply and packaging process stand out?

A: Our supply chain is optimized for rapid dispatch, and each flange is packed to prevent damage, ensuring that you receive high-quality products ready for use.

Q: How does the surface finish improve product performance?

A: The polished and galvanized surface finish enhances corrosion resistance and ensures a longer service life, even in challenging industrial conditions.
