Monel 400 Lap Joint Flange

Get a Price/Quote

MOQ : 100 Pieces

Monel 400 Lap Joint Flange Specification

Features
High Quality

Surface Finish
Polished

Grade
Multple Grades Available

Corrosion Resistant
Yes

Material
Stainless Steel

Standard
ANSI

Surface
Galvanized

Technics
Cold Rolled

Size
Various Sizes Available

Monel 400 Lap Joint Flange Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Monel 400 Lap Joint Flange

Procure the sought-after Monel 400 Lap Joint Flange, championed for its lofty corrosion resistance and robust construction. Manufactured and exported from India, this sizzling product is available in multiple grades and sizes, tailored to diverse applications. Purchase with confidence, as each flange is crafted from premium stainless steel, adhering to ANSI standards for guaranteed quality. The cold-rolled technics, galvanized surface, and polished finish ensure durability and superior aesthetics. As a trusted supplier, trader, and manufacturer, we deliver high-quality flanges meeting the critical needs of various industries.

Versatile Application and Users of Monel 400 Lap Joint Flange

Monel 400 Lap Joint Flanges are widely used in marine, chemical, and oil & gas industries for piping connections requiring superior corrosion resistance. This product is ideal for high-pressure environments, ensuring a secure and reliable joint. Frequently procured by engineers, project managers, and maintenance teams for industrial systems, these flanges deliver long-lasting performance and safety. Their lofty reputation stems from versatile usage in critical operations and demanding conditions.

Flexible Payment Terms, Reliable Supply, and Timely Delivery

Our champion transport services ensure prompt supply and timely arrival of Monel 400 Lap Joint Flanges. We offer flexible payment terms to suit a diverse clientele and maintain ample supply ability to meet urgent and bulk requirements. With streamlined dispatch processes, delivery time is optimized for efficiency and reliability, guaranteeing your products reach the destination as scheduled. Rely on our experience as an exporter and supplier for hassle-free procurement and shipment.

Duplex Flanges Specification

Standards	ASTM A182 / ASME SA182
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2" (15 NB) to 48" (1200NB)
Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Face Types	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Super Duplex Flange Dimensions

NPS (in.)	Duplex Steel Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Duplex Flanges Weight Chart

Pipe Normal Diameter (inch)		Outer diameter Flange	Thicjness Of Flange Minimum	Diameter of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diameter of Bolt Circle	Diameter of Bolt Holes	Number of Bolts	Diameter of Bolts (inch)	KG	LB
1/2"	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2"	0.4	0.9
3/4"	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2"	0.7	1.5
1"	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2"	0.8	1.8
1-1/4"	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2"	1.2	2.6
1-1/2"	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2"	1.5	3.3
2"	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8"	2.3	5.1
2-1/2"	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8"	3.7	8.1
3"	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8"	4.1	9
3-1/2"	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8"	5.1	11.2
4"	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8"	5.9	13
5"	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4"	7	15.4
6"	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4"	8.4	18.5
8"	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4"	13	28.6
10"	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8"	18	39.5
12"	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8"	29	64
14"	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1"	39	86
16"	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1"	47	103
18"	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8"	57	126
20"	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8"	76	167
24"	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4"	97	214

Duplex Flange Pressure Rating Chart

ASME	Pressure Temperature Ratings For Duplex Steel Flanges
Temperature °F	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

FAQs of Monel 400 Lap Joint Flange:

Q: How does the Monel 400 Lap Joint Flange benefit industrial applications?

A: The Monel 400 Lap Joint Flange offers exceptional corrosion resistance and high strength, making it ideal for varied industrial applications in marine, chemical, and oil & gas sectors.

Q: What is the process of purchasing the Monel 400 Lap Joint Flange?

A: Customers can purchase by contacting our sales team directly or placing online orders. We assist during selection, payment, and provide support throughout the transport and delivery process.

Q: When can I expect my Monel 400 Lap Joint Flange delivery after ordering?

A: Delivery time varies by order size and location; however, our streamlined supply chain ensures timely dispatch and prompt arrival as per your requirements.

Q: Where are Monel 400 Lap Joint Flanges mainly used?

A: These flanges are mainly used in piping systems that require corrosion resistance, such as offshore platforms, refineries, and chemical processing plants.

Q: How does the galvanization and polished surface finish enhance the flange quality?

A: The galvanized and polished finish on Monel 400 Lap Joint Flanges increases their durability, resistance to wear and tear, and gives a professional appearance suitable for demanding environments.
