Nickel Alloy 200 Long Weld Neck Flange

Get a Price/Quote

MOQ : 100 Pieces

Nickel Alloy 200 Long Weld Neck Flange Specification

Features
High Quality

Grade
Multple Grades Available

Surface Finish
Polished

Usage
Industrial

Corrosion Resistant
Yes

Standard
ANSI

Surface
Galvanized

Size
Various Sizes Available

Nickel Alloy 200 Long Weld Neck Flange Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About Nickel Alloy 200 Long Weld Neck Flange

Experience the ultimate bargain on Nickel Alloy 200 Long Weld Neck Flangewhere first-class quality meets the lowest price in the market. Manufactured by Indias leading exporter, supplier, manufacturer, and trader, this flange showcases a lustrous polished, galvanized surface, ensuring remarkable corrosion resistance and reliability. Suitable for diverse industrial applications, it is available in multiple sizes and grades in compliance with the ANSI standard. With its high-quality design, you can try now for exceptional performance and durability with every use.

Application Areas of Nickel Alloy 200 Long Weld Neck Flange

Nickel Alloy 200 Long Weld Neck Flange is extensively used in a variety of plants including chemical, petrochemical and power generation facilities. Its robust, corrosion-resistant construction makes it ideal for harsh environments and demanding conditions. Application areas cover pipelines, process equipment, and pressure vessels, ensuring reliable performance in industrial zones. The remarkable properties of this flange guarantee efficiency and safety in critical plant operations.

FOB Port, Certifications and Delivery for Nickel Alloy 200 Long Weld Neck Flange

Our Nickel Alloy 200 Long Weld Neck Flanges are certified to meet industry standards, providing assurance of quality with every order. FOB port options across India allow for timely drop-off and seamless export logistics. Packaging is handled with precision to minimize expenditure and ensure safe transit. We offer prompt delivery times, maximizing value for our customers and streamlining the supply chain from manufacturers to industrial clients.

Duplex Flanges Specification

Standards	ASTM A182 / ASME SA182
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2" (15 NB) to 48" (1200NB)
Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Face Types	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Super Duplex Flange Dimensions

NPS (in.)	Duplex Steel Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Duplex Flanges Weight Chart

Pipe Normal Diameter (inch)		Outer diameter Flange	Thicjness Of Flange Minimum	Diameter of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diameter of Bolt Circle	Diameter of Bolt Holes	Number of Bolts	Diameter of Bolts (inch)	KG	LB
1/2"	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2"	0.4	0.9
3/4"	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2"	0.7	1.5
1"	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2"	0.8	1.8
1-1/4"	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2"	1.2	2.6
1-1/2"	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2"	1.5	3.3
2"	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8"	2.3	5.1
2-1/2"	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8"	3.7	8.1
3"	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8"	4.1	9
3-1/2"	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8"	5.1	11.2
4"	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8"	5.9	13
5"	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4"	7	15.4
6"	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4"	8.4	18.5
8"	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4"	13	28.6
10"	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8"	18	39.5
12"	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8"	29	64
14"	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1"	39	86
16"	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1"	47	103
18"	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8"	57	126
20"	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8"	76	167
24"	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4"	97	214

Duplex Flange Pressure Rating Chart

ASME	Pressure Temperature Ratings For Duplex Steel Flanges
Temperature °F	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

FAQs of Nickel Alloy 200 Long Weld Neck Flange:

Q: How is the Nickel Alloy 200 Long Weld Neck Flange used in industrial applications?

A: This flange is widely utilized in pipelines, process equipment, and pressure vessels, providing a reliable and corrosion-resistant connection in harsh industrial environments.

Q: What sizes and grades of Nickel Alloy 200 Long Weld Neck Flanges are available?

A: A variety of sizes and multiple grades are offered to suit different industrial requirements, ensuring flexibility for diverse application needs.

Q: Where is the FOB port for dropping off Nickel Alloy 200 Long Weld Neck Flanges?

A: The drop-off is arranged at various FOB ports across India, enabling efficient export logistics for international and domestic clients.

Q: What is the process for obtaining certifications and verifying standards for these flanges?

A: All flanges are certified as per industry standards such as ANSI, and documentation can be provided to verify compliance and quality assurance.

Q: When can customers expect delivery after placing an order, and how is packaging handled?

A: Delivery times are prompt, with packaging meticulously prepared to minimize expenditure while ensuring safe arrival at the customers chosen location.

Q: What benefits does the lustrous galvanized finish provide to the Nickel Alloy 200 Long Weld Neck Flange?

A: The polished, galvanized finish delivers enhanced corrosion resistance and a remarkable lustrous appearance, adding durability and visual appeal in industrial settings.
