Super Duplex Steel 2507 Weld Neck Flange

Get a Price/Quote

About Super Duplex Steel 2507 Weld Neck Flange

Explore our clearance on the featured Super Duplex Steel 2507 Weld Neck Flange, renowned for its grandiose durability and illustrious performance. Buy online from an illustrious exporter, manufacturer, supplier, and trader in India. Crafted using noble stainless steel, these flanges offer exceptional corrosion resistance and are available in multiple grades. The polished, galvanized surface ensures premium quality and longevity. Suitable for diverse industrial usages, these ANSI-standard flanges come in various sizes. Take advantage of this opportunity for high-quality, noble engineering components at the lowest price today.

Reliable Industrial Use of 2507 Weld Neck Flanges

The Super Duplex Steel 2507 Weld Neck Flange is widely used for general and specific industrial applications, thanks to its high corrosion resistance and robust build. Designed for use on polished application surfaces, it is ideal in chemical processing, oil & gas, and power generation plants. This illustrious flange is a preferred choice among engineers, plant operators, and industrial project managers requiring reliable, grandiose pipe connections in challenging environments.

Sample Policy and Export Markets for Your Advantage

Our Super Duplex Steel 2507 Weld Neck Flange comes with a flexible sample policy, ensuring you can assess product quality at the lowest price before a grand purchase. Our primary export destinations include domestic markets, Asia, Africa, and Europe. We offer prompt delivery from Indias leading industrial FOB ports, facilitating seamless export and efficient domestic market distribution. Take advantage of this noble opportunity to source reliable industrial components with quick turnaround.

Duplex Flanges Specification

Standards	ASTM A182 / ASME SA182
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2" (15 NB) to 48" (1200NB)
Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Face Types	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Super Duplex Flange Dimensions

NPS (in.)	Duplex Steel Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Duplex Flanges Weight Chart

Pipe Normal Diameter (inch)		Outer diameter Flange	Thicjness Of Flange Minimum	Diameter of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diameter of Bolt Circle	Diameter of Bolt Holes	Number of Bolts	Diameter of Bolts (inch)	KG	LB
1/2"	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2"	0.4	0.9
3/4"	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2"	0.7	1.5
1"	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2"	0.8	1.8
1-1/4"	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2"	1.2	2.6
1-1/2"	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2"	1.5	3.3
2"	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8"	2.3	5.1
2-1/2"	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8"	3.7	8.1
3"	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8"	4.1	9
3-1/2"	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8"	5.1	11.2
4"	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8"	5.9	13
5"	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4"	7	15.4
6"	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4"	8.4	18.5
8"	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4"	13	28.6
10"	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8"	18	39.5
12"	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8"	29	64
14"	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1"	39	86
16"	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1"	47	103
18"	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8"	57	126
20"	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8"	76	167
24"	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4"	97	214

Duplex Flange Pressure Rating Chart

ASME	Pressure Temperature Ratings For Duplex Steel Flanges
Temperature °F	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

FAQs of Super Duplex Steel 2507 Weld Neck Flange:

Q: How is the Super Duplex Steel 2507 Weld Neck Flange used in industrial settings?

A: This flange is typically used to connect pipes, valves, pumps, and other equipment in high-pressure, corrosive environments such as chemical plants, oil & gas industries, and power stations.

Q: What are the main benefits of choosing a 2507 Weld Neck Flange?

A: The main benefits include superior corrosion resistance, high strength due to super duplex steel composition, and a polished, galvanized finish for outstanding durability and longevity.

Q: Where are these flanges manufactured and supplied from?

A: These Super Duplex Steel 2507 Weld Neck Flanges are manufactured, exported, and supplied from India, ensuring high quality and strict adherence to ANSI standards.

Q: What grades and sizes are available for this product?

A: Multiple grades and a wide variety of sizes are available, catering to different industrial requirements and specific application needs.

Q: When should I consider using a corrosion-resistant flange like this?

A: You should opt for a corrosion-resistant flange like the 2507 Weld Neck Flange when working in harsh, corrosive environments, or where longevity and reliability are crucial to system integrity.

Q: How does the sample policy for this product work?

A: Our sample policy allows you to request a product sample at the lowest price for quality verification before making a larger order, supporting confident purchase decisions.
