DSS 2205 Weld Neck Flange

Get a Price/Quote

About DSS 2205 Weld Neck Flange

Grab Yours now a Monumental Deal awaits on the Dazzling DSS 2205 Weld Neck Flange! Crafted from Eminent stainless steel with a polished, galvanized surface, this top industrial component guarantees high corrosion resistance and long-term durability. Multiple grades and sizes suit diverse requirements, meeting ANSI standards for reliability. As a manufacturer, exporter, supplier, and trader from India, we offer premium quality at competitive rates. Elevate your operations with our expertly engineered flange, perfect for robust performance in demanding industrial environments.

Versatile Application & Advantages

The DSS 2205 Weld Neck Flange stands out in both specific and general industrial uses, accommodating various application media including chemicals, water, and gas. Its principal advantage stems from eminent corrosion resistance and high material strength, making it ideal for harsh environments. Whether for refinery pipelines or manufacturing systems, its versatility and reliability ensure consistent, top-tier results for users seeking efficiency and safety in everyday operations.

Flexible Payment Terms & Certified Quality

Benefit from our flexible payment terms designed to suit your budget, ensuring the proposal amount matches the desired rate at the lowest price available. Our DSS 2205 Weld Neck Flanges are certified to stringent international standards, guaranteeing monumental quality and safety. Delivery time is prompt, tailored to your order size and urgency, allowing you to keep projects on schedule while maintaining top industry compliance.

Duplex Flanges Specification

Standards	ASTM A182 / ASME SA182
Dimensions	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Size	1/2" (15 NB) to 48" (1200NB)
Class	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Standard	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Face Types	Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Super Duplex Flange Dimensions

NPS (in.)	Duplex Steel Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Duplex Flanges Weight Chart

Pipe Normal Diameter (inch)		Outer diameter Flange	Thicjness Of Flange Minimum	Diameter of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diameter of Bolt Circle	Diameter of Bolt Holes	Number of Bolts	Diameter of Bolts (inch)	KG	LB
1/2"	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2"	0.4	0.9
3/4"	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2"	0.7	1.5
1"	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2"	0.8	1.8
1-1/4"	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2"	1.2	2.6
1-1/2"	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2"	1.5	3.3
2"	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8"	2.3	5.1
2-1/2"	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8"	3.7	8.1
3"	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8"	4.1	9
3-1/2"	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8"	5.1	11.2
4"	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8"	5.9	13
5"	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4"	7	15.4
6"	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4"	8.4	18.5
8"	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4"	13	28.6
10"	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8"	18	39.5
12"	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8"	29	64
14"	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1"	39	86
16"	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1"	47	103
18"	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8"	57	126
20"	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8"	76	167
24"	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4"	97	214

Duplex Flange Pressure Rating Chart

ASME	Pressure Temperature Ratings For Duplex Steel Flanges
Temperature °F	Class 150	Class 300	Class 400	Class 600	Class 900	Class 1500	Class 2500
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

FAQs of DSS 2205 Weld Neck Flange:

Q: How is the DSS 2205 Weld Neck Flange typically used in industrial settings?

A: The DSS 2205 Weld Neck Flange is commonly employed to connect pipes securely in high-pressure, corrosive environments such as chemical plants, refineries, and general water systems.

Q: What benefits does the galvanized and polished surface finish offer?

A: The polished, galvanized surface enhances corrosion resistance, prolongs the flanges lifespan, and maintains a dazzling appearance even in demanding conditions.

Q: When can I expect delivery after placing an order?

A: Delivery times vary based on your location and order quantity, but we strive to provide prompt shipping to meet your project deadlines.

Q: Where can I use this flange based on available sizes and grades?

A: With multiple grades and various sizes available, the DSS 2205 Weld Neck Flange can be applied across diverse industrial sectors, adapting to different process requirements.

Q: What certifications do these flanges hold for quality assurance?

A: Our flanges are manufactured in compliance with ANSI and other international standards, ensuring certified, reliable performance for all applications.

Q: How does the purchase process for DSS 2205 Weld Neck Flanges work?

A: Simply reach out with your requirements; we will provide a detailed proposal amount at the lowest price and assist you through order confirmation, payment, and shipment.
